Description
Features :
General Specification :
| Cooling Features : | |||
|---|---|---|---|
| Type | Direct Cool | ||
| Capacity : | |||
| Gross Volume | 205 Ltr. | ||
| Net Volume | 205 Ltr. | ||
| Gross Weight | 49 ± 2 (Kg) | ||
| Net Weight | 43 ± 2 (Kg) | ||
| Performance : | |||
| Climatic Type (SN, N, ST, T) | N ~ ST | ||
| Rated Voltage/ Hz | 220 ~ 240/ 50 | ||
| Compressor Input Power (Watt) | V 01.01-134 V 02.01-98 V 03.01-98 V 04.01-98 V 05.01-98 V 06.01-118 |
||
| Compressor Type | V 01.01-RSIR V 02.01-RSCR V 03.01-RSCR V 04.01-RSCR V 05.01-RSCR V 06.01-RSCR |
||
| Wide voltage range | V 05.01, 145V to 260V V 06.01, 145V to 260V |
||
| Cooling Effect | Freezer Cabinet Less than -18℃ | ||
| General Features: | |||
| Temperature Control (Electronic/ Mechanical): | Mechanical | ||
| Defrosting (Automatic/ Manual) | Manual | ||
| Reversible Door | N/A | ||
| Handle (Recessed/ Grip) | Yes | ||
| Lock | Yes | ||
| Refrigerant | V 01.01-R134a V 02.01-R600a V 03.01-R600a V 04.01-R600a V 05.01-R600a V 06.01-R600a |
||
| Condenser | Steel | ||
| Capillary | Copper | ||
| Polyurethane foam blowing agent | Cyclopentene [Eco-friendly (100% CFC & HCFC Free) Green Technology] |
||
| Recommended voltage stabilizer capacity (1000VA) | V 01.01 | ||
| Freezer Compartment : | |||
| Exterior Material | Painted Steel (PCM) | ||
| Interior Material | Embossed Aluminium (Al2) | ||
| Ice/ cold water Dispenser | No | ||
| Shelf (Material/No) | Wire/1 | ||
| Drawer | No | ||
| Basket | Wire/1 | ||
| Interior Lamp | Yes | ||
| Dimensions (Net) : | |||
| Width/mm | 962 | ||
| Depth/mm | 585 | ||
| Height/mm | 852 | ||
| Dimensions (Packing) : | |||
| Width/mm | 1010 | ||
| Depth/mm | 620 | ||
| Height/mm | 890 | ||
| Loading quantity (20ft/40ft.40HQ) | 36/76/114 | ||
Warranty Information:
Residential Use:
– Replacement Guarantee: 1 Year (Condition Apply)
– Main Parts (Compressor): 12 Years
– Replacement Guarantee: 1 Year (Condition Apply)
– Main Parts (Compressor): 12 Years
– Door: 3 Years *
– Spare Parts: 4 Years *
– After Sales Service:5 Years *Commercial Use:
– Main Parts (Compressor): 4 Years
– Spare Parts: 4 Years *
– After Sales Service:5 Years *Commercial Use:
– Main Parts (Compressor): 4 Years
– Door: 1 Years *
– Spare Parts: 2 Years *
– After Sales Service: 2 Years *
– Spare Parts: 2 Years *
– After Sales Service: 2 Years *
Note:
This warranty does not cover the following cases:
1. Any damage due to accident, electrical fault, natural causes, negligence or improper installation.
2. Any damage or failure caused by unauthorized modification or alteration.
3. Products with original serial numbers that have been removed, distorted or cannot be readily recognized.
Authority keeps the right to change, extend, correct, stop or cancel the warranty period without any prior notice.
*This warranty covers only manufacturing defects in products & workmanship, subject to verification by company personnel.
