Description
Features :
General Specification :
| HARDWARE CONFIGURATION | |||
|---|---|---|---|
| CPU | ARM Cortex Quad Core A53 | ||
| GPU | ARM Mali-GP31 | ||
| DDR RAM Size | 512 MB | ||
| eMMC Flash | 4 GB (*Available storage will be less than the total memory due to storage of operating system and software pre-installed on the device.) | ||
| SYSTEM INFO | |||
| OS | CloudTV OS | ||
| Screen Mirroring | Yes (KindLink) | ||
| YouTube | Yes | ||
| Netflix | No | ||
| Wifi Built in | 2.4 GHz | ||
| HDMI (CEC) | Yes | ||
| DISPLAY | |||
| Backlight Unit | DLED | ||
| Aspect Ratio | 16:09 | ||
| Panel Size | 813 mm | ||
| Display Resolution | 1366 X 768 | ||
| Brightness | 170 ± 10 cd/m2 | ||
| Contrast | 1100:1 (For IPS display), 3000:1 (For VA display) | ||
| Color | Black | ||
| Frame Rate | 60 Hz | ||
| POWER | |||
| Power Supply | AC 110V-240V 50/60Hz | ||
| Power Consumption (TV On | <50W | ||
| Power Consumption (STB) | < 0.5 W | ||
| AUDIO | |||
| Audio Power Output | 2 X 10 Watt ( Box Speaker) | ||
| Sound Mode | User, Standard, Vivid, Sports, Movie, Music, News | ||
| Sound Control | 2 Ch Speaker System | ||
| TERMINAL SPECIFICATIONS | |||
| RJ45 (LAN Port) | 1 | ||
| AV In | 1 | ||
| HDMI In | 3 | ||
| Earphone Out | 1 | ||
| COAX Out | 1 | ||
| RF In | 1 | ||
| USB 2.0 | 2 | ||
| SUPPORTED MEDIA FORMATS | |||
| Audio | MP3; WAV, WMA | ||
| Picture | JPEG,BMP,PNG | ||
| Video | MP4;MPG; MOV; DAT; MKV;3GP | ||
| Text | TXT | ||
| Subtitle | SRT; SUB | ||
| ANALOG MODULE | |||
| Video system | PAL/ SECAM/ NTSC | ||
| Sound system | BG/ D/ K/ I | ||
| Receiving Range | 48.25MHz – 863.25 MHz | ||
| Receive Channel | 99 | ||
| OTHER ATTRIBUTES | |||
| TV with Stand (L × W × H) | 720 mm x 190 mm x 480 mm | ||
| TV without Stand (L × W × H) | 720 mm x 65 mm x 430 mm | ||
| TV Shipping dimensions (L × W × H) | 775 mm x 83 mm x 482 mm | ||
| TV with Stand Weight | 3.32 Kg | ||
| TV without Stand Weight | 3.28 Kg | ||
| TV Shipping Weight | 4.42 Kg | ||
| LOADING CAPACITY | |||
| 40 HQ Container | Approx. 1885 Units | ||
| 20 GP Container | Approx. 760 pcs Units | ||
Warranty Information:
- LED Panel: 2 Years
- Spare Parts: 2 Years
- Free Service: 3 Years
Note: This warranty does not cover any damage due to accident, electricity fault, natural causes or negligence. And Authority keeps the power to change, expend, correction, stop or cancel the warranty period without any prior notice.
