Description
Features :
– Maintenance free (No water topping-up required)
– Long Back up time & Extended Life
– PbCaSn alloy for plate grids
– Non-Spillable battery
– Low self-discharge rate, lower than 3% capacity loss per month due to high quality raw material
– Usable in any orientation (excluding used inverted)
– Absorbent Glass Mat technology for efficient gas recombination which extends cycle life and prevent micro short circuit
– Designed as per IEC 61096-2 & JIS C8702-01 Standard
– Flame-retardant ABS material increases the strength of battery container
– Silver-coated copper terminals for improving the electric conductivity
– Long Back up time & Extended Life
– PbCaSn alloy for plate grids
– Non-Spillable battery
– Low self-discharge rate, lower than 3% capacity loss per month due to high quality raw material
– Usable in any orientation (excluding used inverted)
– Absorbent Glass Mat technology for efficient gas recombination which extends cycle life and prevent micro short circuit
– Designed as per IEC 61096-2 & JIS C8702-01 Standard
– Flame-retardant ABS material increases the strength of battery container
– Silver-coated copper terminals for improving the electric conductivity
General Specification :
| Nominal voltage | 6 cell, 12 Volt |
| Nominal Capacity | 20 Hour, 7.5 AH |
| Weight | 2050 ± 25 grams |
| Internal Resistance | Fully charge Battery, 35 mΩ |
| Maximum Charging Current | 2.25 A |
| Float Charging Voltage | 14.4~14.8 VDC |
| Product Dimension | Length- 151 mm |
| Width- 65 mm | |
| Height- 94 mm | |
| Terminal | F2 |
Application :
– Uninterrupted Power Supply (UPS)
– Emergency backup power supply
– Emergency light
– Alarm and security system
– Aircraft signal
– Electronic apparatus and equipment
– Electric Power System (EPS)
